Panel Wire Mesh Welding Machine
OLT Machine - provides OEM & ODM services for all kinds of wire mesh machine.
Language
OLT Machine - provides OEM & ODM services for all kinds of wire mesh machine.
Using highly advanced technologies and newest methods,Hebei oulite import & export trading Co.,Ltd has developed Popular high quality automatic chicken cage mesh welding machine. It is on sale starting now and we welcome your inquiry. Compared with other similar China products in the market, wire drawing machine ,galvanized wire production line,chain link fence machine,wire mesh making machine ,nail making machine ,gabion box machine，welded wire mesh machine ，razor barbed wire machine,barbed wire machine etc. it can be very stable and long-lasting when applied in the field(s) of Wire Mesh Making Machines. So, shake hands with us, expand your business, and increase your clientele.
| Condition: | New | Machine Type: | Wire Mesh Welding Machine |
| Video outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty of core components: | 1 Year |
| Core Components: | PLC, Motor | Wire Diameter (mm): | 2 - 4 mm |
| Production Capacity: | 0-90times/min | Place of Origin: | China |
| Brand Name: | OLT | Model Number: | OLT-WMW-01 |
| Weight (KG): | 16000 | Power (kW): | 11 |
| Key Selling Points: | High Productivity | Warranty: | 1 Year |
| Applicable Industries: | Manufacturing Plant, Home Use, Retail, Construction works | Showroom Location: | None |
| Product name: | Popular high quality automatic chicken cage mesh welding machine | Welding Speed: | 0-90Times/Min |
| Mesh size: | 100-300mm | Mesh Width: | 2m |
| Wire diameter: | 2-4mm | Voltage: | Customer's Request |
| Motor: | 15KW | Color: | Customer's Request |
| Pressure method: | Spring pressure | OVerall Dimension: | 2200*5100*2100mm |
Wire diameter | 5-12mm | Welding method | Silicon controlled synchronous control |
Hole size | 150-300mm | Transformer power | 250-315KVA |
Mesh width | 3m | Machine size | 22000*5500*2100mm |
Wire feeding mode | Pre-straight and cutting | Machine weight | 16.0T |
Welding speed | 60-70times/min | Transformer | 160KVA×11 |
Welding spot | 21 | Motor | 11KW frequency conversion |
Voltage | 380V 3P 50HZ | Way of pressure | Mechanical pressure |
Wire diameter | 3-6mm | Voltage | 380V 3P 50HZ |
Hole size | 50-300mm | Maximum distance from outside transformer | 150m |
Width | 2.5m | Weight | 6.0ton |
Welding spot | 51pcs | Overall dimension | 6500×5000×1900mm |
Welding speed | 50-60times/mi | Welding method | Silicon controlled synchronous control |
Transformer | 150KVA*6 | Main motor | 5.5kw with frequency conversion |
Cross wire | pre-straightening and cutting | Line wire | pre-straightening and cutting |
Wire diameter | 3-6mm | pressure method | Mechanical pressure |
Hole size | 100-300mm | wire feeding way | pre-straightening and cutting |
Mesh width | 3m | Main motor power | 5.5kw with frequency converison |
Welding spot | 30pcs | Weight approx | 20ton |
Welding way | silicone control synchronous control | Overall dimension approx | 30m*6m×3m |
Transformer capacity | 150-200KVA | Line wire adjustment mode | manual adjustment |
Welding speed | 60-70times/min | Voltage | 380V 3P 50HZ |
Professional customer service keeps online communication 24 hours a day.
Products are sold to India, Pakistan, South Africa, Indonesia, USA, Uzbekistan, Tajikistan, Nepal, Egypt, Nigeria, Kenya, Tanzania and other countries
Oulite import&export trading Co., Ltd.(OLT Machine) is an enterprise specialized in Research, design, manufacturing, sales and service of wire mesh machinery and equipment.
