If you’re looking for straight type iron and steel wire drawing machine Machinery/Straight Line Pulling Machine distributors and suppliers, OLT features product suppliers and wholesalers for you. Each Wire Drawing Machines goes through quality control to ensure they are ready for sale. So you can buy it in large quantitiy.
Xinjiang Oulite Wire Mesh Products Co.,Ltd maintains stringent norms of quality to manufacture straight type iron and steel wire drawing machine Machinery/Straight Line Pulling Machine. Compared with other similar , China products in the market, wire drawing machine ,galvanized wire production line,chain link fence machine,wire mesh making machine ,nail making machine ,gabion box machine，welded wire mesh machine ，razor barbed wire machine,barbed wire machine etc. it can be very stable and long-lasting when applied in the field(s) of Wire Drawing Machines. In the future,Xinjiang Oulite Wire Mesh Products Co.,Ltd will continue to introduce outstanding talents and learn advanced technology, win the initiative in market competition, and clear road obstacles to achieve the goal of becoming a world-class enterprise.
| Condition: | New | Inlet Diameter: | 3.2mm,6.5mm,8mm |
| Outlet Diameter: | 0.8mm,2.0mm,5.4mm | Video outgoing-inspection: | Provided |
| Machinery Test Report: | Not Available | Marketing Type: | New Product 2026 |
| Warranty of core components: | 1 Year | Core Components: | Motor, PLC, Capstan |
| Place of Origin: | China | Brand Name: | OLT |
| Power: | 11kw | Weight: | 5000 |
| Year: | new | Warranty: | 1 Year, 12 months |
| Key Selling Points: | Easy to Operate | Applicable Industries: | Building Material Shops, Manufacturing Plant, Construction works |
| Showroom Location: | None | Product Name: | straight type iron and steel wire drawing machine Machinery |
| Motor: | Inverted motor | Control system: | PLC |
| PLC: | Siemens | Drawing material: | High, medium, low carbon steel wire |
| Drive mode: | Deduction gear | Main steel plate thickness: | 16mm |
| Warranty of capstan: | 24 months | Color: | Customizable |
Straight wire drawing machine is a common metal wire processing equipment, straight wire drawing machine, can be high, medium and low carbon steel wire, stainless steel wire, copper wire, alloy copper wire, aluminum alloy wire, etc., for elongation processing.
| Model | LZ400 | LZ550 | LZ700 | |
| Inlet Wire Dia. | mm | 3.2 | 6.5 | 8 |
| Outlet Wire Dia. | mm | 0.8 | 2.0 | 5.4 |
| Number of drawing capstan | 8 | 9 | 4 | |
| Single Power | kw | 11 | 22 | 22 |
| Max speed | m/s | 12 | 12 | 10 |
| Dia.of capstan | mm | 400 | 550 | 700 |
| Drive mode | Deduction gear | Deduction gear | Deduction gear | |
| Operation | Touch screen | Touch screen | Touch screen |
Equipment should be inspected monthly (closed for 4 hours) for
thorough maintenance and overhaul.
Daily maintenance:
1) Keep the outside of the equipment clean and check that the air supply lines and quick connectors are good.
2) Lubrication of the upper and lower bearing housings and the lifting screw (oil gun refueling).
3) Check the belt and its tension (if the tension is too loose, adjust to the appropriate level).
Professional customer service keeps online communication 24 hours a day.
Products are sold to India, Pakistan, South Africa, Indonesia, USA, Uzbekistan, Tajikistan, Nepal, Egypt, Nigeria, Kenya, Tanzania and other countries
