OLT Machine - provides OEM & ODM services for all kinds of wire mesh machine.
Hebei oulite import & export trading Co.,Ltd relying on years of technical accumulation and industry experience, organically combining traditional craftsmanship with modern technology, successfully developed Good quality factory automatic wire drawing drawing machine. The product is widely used to tackle the problems arising in the field(s) of Wire Drawing Machines. OLT has been dedicated to the design, R&D, manufacturing, and updates of wire drawing machine ,galvanized wire production line,chain link fence machine,wire mesh making machine ,nail making machine ,gabion box machine，welded wire mesh machine ，razor barbed wire machine,barbed wire machine etc.. We fully hope that we can satisfy customers from different fields, countries, and regions by offering them high-quality products and professional service. If you have any questions or problems, please contact us at any time through the contact information listed on our website.
| Condition: | New | Video outgoing-inspection: | Provided |
| Machinery Test Report: | Provided | Marketing Type: | New Product 2020 |
| Warranty of core components: | 1 Year | Core Components: | Motor |
| Place of Origin: | Hebei, China | Brand Name: | OLT |
| Weight: | 2000 | Warranty: | 1 Year, One year |
| Key Selling Points: | High Productivity | Applicable Industries: | Other |
| Showroom Location: | None | Name: | pulley wire drawing machine |
| Usage: | drawing wire | Machine Type: | Full automatic |
| Wire diameter: | 6.5-2.0mm | Power: | 18kw |
| Voltage: | 380V 50Hz 3Phase/Customized | Color: | Green, Blue, etc |
| After-sales Service Provided: | Video technical support | After Warranty Service: | Field maintenance and repair service |
Pulley Type wire drawing machine | ||||||||||
Max inlet wire diameter (mm) | min inlet wire diameter (mm) | Drawing Passage | Motor(KW) |
Production Speed (m/min)
| Production Capacity (T/24hours) | |||||
6.5 | 3.8 | 4 | 15*4+1.5 | 100-120 | 12-15(3.8mm) | |||||
4.0 | 2.0 | 5 | 7.5*5+1.5 | 150-200 | 5-6(2.0mm) | |||||
Specification | LZ-560 | ||||||
Drum diameter | 560mm | ||||||
Max inlet wire tensile strength | 1300Mpa | ||||||
Drawing numbers | 2-13 | ||||||
Inlet wire diameter max | 6.5mm | ||||||
Outlet wire diameter min | 1.35mm | ||||||
Max wire speed | 15m/s | ||||||
Motor | 160-220KW | ||||||
Water Tank Wire Drawing Machine Paratemter | ||||||||||||
Type | Max.Inlet Diameter(mm) | Min.Outlet Diameter(mm) | Drawing Passage | Motor Power(kw) | Production Speed(m/min) | Production Capacity(T/24h) | ||||||
WWM-1 | 4.0-3.5 | 1.8-1.4 | 8-10 | 37+1.5 | 150-200 | 5-8 | ||||||
WWM-2 | 2.0 | 0.5-1.0 | 10-12 | 15+2.2 | 280-350 | 1-1.5 | ||||||
Professional customer service keeps online communication 24 hours a day.
Products are sold to India, Pakistan, South Africa, Indonesia, USA, Uzbekistan, Tajikistan, Nepal, Egypt, Nigeria, Kenya, Tanzania and other countries
Oulite import&export trading Co., Ltd.(OLT Machine) is an enterprise specialized in Research, design, manufacturing, sales and service of wire mesh machinery and equipment.
